Falcon 1000W / 1228Wh

Power Station with 4x AC Outlet

Tested and Certified

Available for September/October 2021

Category:

Description

  • PORTABLE ENERGY | Litionite Falcon is a comfortable portable power station with a modern design and a super capacity of 1228Wh. It has a wide and versatile range of outputs: USB Quick Charge 3.0, 100W USB Type-C PD, 1000W AC sockets, DC and cigarette lighter.
  • VERSATILE | The Litionite products are highly evaluated for their versatility. While inheriting the strengths of the power station, it has been upgraded with all the outputs of typical sine wave models such as AC, USB, and DC, and can supply power to 13 devices at the same time.
  • SUPER FAST CHARGING TECHNOLOGY | Litionite has developed its own Super-Q super-fast charging technology to reduce charging time. It reaches 900Wh per hour when charging with AC power and it takes only 1.5 hours to fully charge a battery with a capacity of 1.228Wh.
  • NO NEED AC ADAPTER | Conventional charging technology requires an adapter that converts alternating current to direct current, which is annoying and inconvenient. The Super-Q  allows direct current input with only one electric cord.
  • 3 CHARGING METHODS | There are three types of charging to power station: AC, solar panel, and cigar socket, so you can change the charging method according to the situation at that time, and you can charge anytime, anywhere.
    – Charging time by AC: 1.5 hours.
    – Charging time by solar power (200W): 10-12 hours.
    – Charging Time by 12V car cigar socket: 7-8 hours.
  • SOLAR PERFORMANCE | The power station can input by solar power generation of up to 200W, and by using the MPPT method that can always control unstable voltage and power and take out the maximum amount of power, it is one rank higher even in solar charge.
  • USE AC ELECTRICITY AS AT HOME | You can use general household appliances such as small refrigerators, rice cookers, and microwave ovens without any inconvenience. The power station is a sine wave model that stabilizes the power supply to the device, and it is possible to use an electric vehicle equipped with a high-power motor, so you can work outdoors without problems even in places away from the outlet. You can to be.
  • EQUIPPED WITH UPS FUNCTION | By always connecting power station to your PC while working, you don’t have to worry about power outage any more. UPS (Uninterruptible Power Supply) allows power station immediately activate in 10ms when power outage occurs so that your work will not be interrupted. Nowadays, working from home is the trend and power station with UPS function is recommended to protect important work data.
  • ADVANCED, RELIABLE AND SAFE SYSTEM | According to the National Institute of Technology and Evaluation (NITE), 17 fatal accidents of carbon monoxide poisoning have occurred in portable generators used in the event of a power outage due to heavy snow, and they are used indoors or in tents. Litionite Cargo that does not emit noise or exhaust gas by using an advanced battery management system (BMS) such as temperature control, overvoltage / overcurrent protection, and short circuit prevention to monitor voltage / temperature / current and charge the battery. It realizes important functions such as grasping the current and cell balancing of the lithium-ion battery, preventing accidents and protecting the battery and terminal.
  • PASS THROUGH | This power station is compatible with the Pass Through function, this means that you can charge the generator and devices (laptops/smartphones) connected to it at the same time.
  • POWER DELIVERY (PD) | The future of connectivity is here, a single port and connector to unify all our devices. In fact, this power station has been also designed to charge laptops and other high power devices with USB TYPE-C power port (up to 100W).
  • LCD DISPLAY | It is equipped with a large LCD display, the content displayed is as follows:
    Input power – Output Power – Remaining battery – Discharge/Charge time – AC charging icon – Anderson charging icon – Battery over – Temperature icon – Overcurrent icon – No battery pack icon – Dead battery icon – AC on icon – USB on icon – DC on icon.
  • SOLAR COMPATIBILITY | We recommend to charge Power Station or extra detachable battery by our portable Solar Panels (sold separately): Arun 110W, Arun 160W, Carve 100W.
    The power station supports up to:
    – 1x Arun 160W solar panel.
    – 1x Arun 110W solar panel.
    – 1x Carve 100W solar panel.
  • WORKING TIME | How to calculate the power supply time in hours for AC output:
    Working time = 1228Wh x 0.8 (power loss value) / power (W) of the device to be powered.
    Let’s take an example with a device that consumes 100 watts.
    In this case the working time calculation of the power generator is: 1228Wh x 0.8 / 100W = 10 hours approximately.

Additional information

Weight product:

14.5 kg

Dimension:

34 x 30.6 x 22.5 cm

Color:

Black

Material:

The shell is made of ABS + PC fireproof plastic material, which is safe and environmentally friendly. It is non-toxic and harmless when heated.

Capacity:

1228Wh / 3.2V / 384Ah

Battery Type:

LiFePO4

Input:

AC: 1000W
Anderson: 200W, 12-30V/7A Max.
DC: 200W, 12-30V/7A Max.

Solar Controller:

12V-30V / Max 200W

AC Output:

4x Ports Rated power: 1000W – Peak power: 2000W (Shared on 4x AC ports) – 220V 50Hz / 110V 60Hz – Universal socket

AC Waveform:

Pure Sine Wave

Type-C output:

2x Port PD 100W

USB output:

4x 18W Ports Quick Charge 3.0 – 5V-3A, 9V-2A, 12V-1.5A

DC output:

2x Ports 13.6V-8A, 108.8W Max

Cigarette lighter output:

1x Port 13.6V-8A, 108.8W Max

Accessories included:

1x AC Power cord
1x car charger adapter
